Specifications

• General

  Type

  Large Excavators

  Operating Weight

  32.6  ton

  71870.71  lb

  Bucket Capacity

  1.47  m³

  1.92  yd³

• Engine

  Emission

  STAGE V

  Engine model

  HYUNDAI DX08

  HYUNDAI DX08

  Rated Power

  278  kW / 1,800 rpm

  372  hp / 1,800 rpm

  Max. Torque

  125.43  kgf·m / 1,300 rpm

  906.95  lbf.ft / 1,300 rpm

• Hydraulic System

  Main Pumps Rated Flow

  2x285  ℓ/min

  2x285  ℓ/min

  Implement Circuit

  -

• Tank Capacity

  Fuel Tank

  500  ℓ

  132.19  gal

  Hydraulic Tank

  164  ℓ

  43.36  gal

  DEF/ ADBLUE Tank

  74  ℓ

  19.56  gal

• Performance

  Swing Speed

  9.3  rpm

  9.3  rpm

  Travel Speed

  5.2  km/h

  3.23  mph

  Max. Traction Force

  27,700  kgf

  12564.51  lbf

  Max. Gradeability

  35  deg

  35  deg

  Bucket Digging Force (ISO)

  21,006  kgf

  9528.16  lbf

  Arm Digging Force (ISO)

  14,378  kgf

  6521.75  lbf

• Dimensions

  Overall Length

  10,585  mm

  34'9"  ft.in

  Overall Width

  3,200  mm

  10'6"  ft.in

  Overall Height

  3,235  mm

  10'7"  ft.in

  Tail Swing Radius

  3,230  mm

  10'7"  ft.in

  Tumbler Distance

  4,040  mm

  13'3"  ft.in

  Ground Clearance

  473  mm

  1'7"  ft.in

• Operating Range

  Boom Length

  6,245  mm

  20'6"  ft.in

  Arm Length

  3,100  mm

  10'2"  ft.in

  Max. Digging Reach

  10,670  mm

  35'0"  ft.in

  Max. Digging Depth

  7,280  mm

  23'11"  ft.in

  Max. Digging Height

  10,210  mm

  33'6"  ft.in

  Max. Dumping Height

  7,300  mm

  23'11"  ft.in

  Min. Swing Radius

  4,020  mm

  13'2"  ft.in
