Specifications

• General

  Type

  Medium Excavators

  Operating Weight

  23  ton

  50706.33  lb

  Bucket Capacity

  1.05  m³

  1.37  yd³

• Engine

  Emission

  STAGE V

  Engine model

  DX05

  DX05

  Rated Power

  141  kW / 1,700 rpm

  189  hp / 1,700 rpm

  Max. Torque

  84.6  kgf·m / 1,400 rpm

  611.72  lbf.ft / 1,400 rpm

• Hydraulic System

  Main Pumps Rated Flow

  2x212.5  ℓ/min

  2x212.5  ℓ/min

  Implement Circuit

  350  kgf/cm²

  4978.19  psi

• Tank Capacity

  Fuel Tank

  397  ℓ

  104.96  gal

  Hydraulic Tank

  393  ℓ

  103.9  gal

  DEF/ ADBLUE Tank

  57.2  ℓ

  15.12  gal

• Performance

  Swing Speed

  -

  Travel Speed

  5.2  km/h

  3.23  mph

  Max. Traction Force

  23,374  kgf

  10602.27  lbf

  Max. Gradeability

  35  deg

  35  deg

  Bucket Digging Force (ISO)

  15,200  kgf

  6894.6  lbf

  Arm Digging Force (ISO)

  10,800  kgf

  4898.8  lbf

• Dimensions

  Overall Length

  9,580  mm

  31'5"  ft.in

  Overall Width

  2,990  mm

  9'10"  ft.in

  Overall Height

  3,065  mm

  10'1"  ft.in

  Tail Swing Radius

  2,906  mm

  9'6"  ft.in

  Tumbler Distance

  3,650  mm

  11'12"  ft.in

  Ground Clearance

  450  mm

  1'6"  ft.in

• Operating Range

  Boom Length

  5,700  mm

  18'8"  ft.in

  Arm Length

  2,900  mm

  9'6"  ft.in

  Max. Digging Reach

  9,475  mm

  31'1"  ft.in

  Max. Digging Depth

  6,620  mm

  21'9"  ft.in

  Max. Digging Height

  9,535  mm

  31'3"  ft.in

  Max. Dumping Height

  6,805  mm

  22'4"  ft.in

  Min. Swing Radius

  3,560  mm

  11'8"  ft.in
