Excavators
HX130LCR
-
Type
Medium Excavators
-
Operating Weight
12.7 ton
-
Emission
TIER 4f
-
Rated Power
74 kW / 2,200 rpm
- Catalog
Specifications
-
General
Type
Medium Excavators
Operating Weight
12.7 ton
Bucket Capacity
0.4 m³
-
Engine
Emission
TIER 4f
Engine model
PERKINS 854F
Rated Power
74 kW / 2,200 rpm
Max. Torque
43 kgf·m / 1,200 rpm
-
Hydraulic System
Main Pumps Rated Flow
2x126 ℓ/min
Implement Circuit
330 kgf/cm²
-
Tank Capacity
Fuel Tank
240 ℓ
Hydraulic Tank
96 ℓ
DEF/ ADBLUE Tank
-
-
Performance
Swing Speed
12.6 rpm
Travel Speed
5.5 km/h
Max. Traction Force
11,400 kgf
Max. Gradeability
35 deg
Bucket Digging Force (ISO)
8,954 kgf
Arm Digging Force (ISO)
5,716 kgf
-
Dimensions
Overall Length
6,780 mm
Overall Width
2,590 mm
Overall Height
3,165 mm
Tail Swing Radius
1,500 mm
Tumbler Distance
2,610 mm
Ground Clearance
900 mm
-
Operating Range
Boom Length
4,300 mm
Arm Length
2,260 mm
Max. Digging Reach
7,690 mm
Max. Digging Depth
5,020 mm
Max. Digging Height
8,110 mm
Max. Dumping Height
5,880 mm
Min. Swing Radius
2,340 mm
- These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog. - The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
