Specifications

• General

  Type

  Medium Excavators

  Operating Weight

  20.5  ton

  45194.77  lb

  Bucket Capacity

  0.92  m³

  1.2  yd³

• Engine

  Emission

  ~TIER 2

  Engine model

  6B5.9-C

  6B5.9-C

  Rated Power

  105  kW / 2,000 rpm

  140  hp / 2,000 rpm

  Max. Torque

  57.6  kgf·m / 1,400 rpm

  416.49  lbf.ft / 1,400 rpm

• Hydraulic System

  Main Pumps Rated Flow

  2 × 203  ℓ/min

  2 × 203  ℓ/min

  Implement Circuit

  350  kgf/cm²

  4978.19  psi

• Tank Capacity

  Fuel Tank

  340  ℓ

  89.89  gal

  Hydraulic Tank

  150  ℓ

  39.66  gal

  DEF/ ADBLUE Tank

  -

• Performance

  Swing Speed

  10.6  rpm

  10.6  rpm

  Travel Speed

  5.8  km/h

  3.6  mph

  Max. Traction Force

  22,793  kgf

  10338.73  lbf

  Max. Gradeability

  35  deg

  35  deg

  Bucket Digging Force (ISO)

  15,204  kgf

  6896.42  lbf

  Arm Digging Force (ISO)

  12,716  kgf

  5767.88  lbf

• Dimensions

  Overall Length

  9,575  mm

  31'5"  ft.in

  Overall Width

  2,990  mm

  9'10"  ft.in

  Overall Height

  3,010  mm

  9'11"  ft.in

  Tail Swing Radius

  2,845  mm

  9'4"  ft.in

  Tumbler Distance

  3,270  mm

  10'9"  ft.in

  Ground Clearance

  450  mm

  1'6"  ft.in

• Operating Range

  Boom Length

  5,700  mm

  18'8"  ft.in

  Arm Length

  2,400  mm

  7'10"  ft.in

  Max. Digging Reach

  9,525  mm

  31'3"  ft.in

  Max. Digging Depth

  5,950  mm

  19'6"  ft.in

  Max. Digging Height

  9,660  mm

  31'8"  ft.in

  Max. Dumping Height

  6,865  mm

  22'6"  ft.in

  Min. Swing Radius

  3,400  mm

  11'2"  ft.in
