Specifications

• General

  Type

  Large Excavators

  Operating Weight

  35.6  ton

  78484.58  lb

  Bucket Capacity

  1.27  m³

  1.66  yd³

• Engine

  Emission

  TIER 4f

  Engine model

  HYUNDAI / DL08

  HYUNDAI / DL08

  Rated Power

  270  kW / 1,800 rpm

  362  hp / 1,800 rpm

  Max. Torque

  130  kgf·m / 1,300 rpm

  939.99  lbf.ft / 1,300 rpm

• Hydraulic System

  Main Pumps Rated Flow

  2x288  ℓ/min

  2x288  ℓ/min

  Implement Circuit

  350  kgf/cm²

  4978.19  psi

• Tank Capacity

  Fuel Tank

  490  ℓ

  129.54  gal

  Hydraulic Tank

  175  ℓ

  46.27  gal

  DEF/ ADBLUE Tank

  62  ℓ

  16.39  gal

• Performance

  Swing Speed

  9.81  rpm

  9.81  rpm

  Travel Speed

  -

  Max. Traction Force

  37,800  kgf

  17145.79  lbf

  Max. Gradeability

  35  deg

  35  deg

  Bucket Digging Force (ISO)

  20,300  kgf

  9207.92  lbf

  Arm Digging Force (ISO)

  15,100  kgf

  6849.24  lbf

• Dimensions

  Overall Length

  9,975  mm

  32'9"  ft.in

  Overall Width

  3,600  mm

  11'10"  ft.in

  Overall Height

  3,425  mm

  11'3"  ft.in

  Tail Swing Radius

  1,900  mm

  6'3"  ft.in

  Tumbler Distance

  4,040  mm

  13'3"  ft.in

  Ground Clearance

  475  mm

  1'7"  ft.in

• Operating Range

  Boom Length

  6,245  mm

  20'6"  ft.in

  Arm Length

  3,100  mm

  10'2"  ft.in

  Max. Digging Reach

  10,820  mm

  35'6"  ft.in

  Max. Digging Depth

  6,970  mm

  22'10"  ft.in

  Max. Digging Height

  11,200  mm

  36'9"  ft.in

  Max. Dumping Height

  8,065  mm

  26'6"  ft.in

  Min. Swing Radius

  1,900  mm

  6'3"  ft.in
