Specifications

• General

  Type

  Medium Excavators

  Operating Weight

  27  ton

  59524.82  lb

  Bucket Capacity

  1.17  m³

  1.53  yd³

• Engine

  Emission

  STAGE V

  Engine model

  HYUNDAI DX05

  HYUNDAI DX05

  Rated Power

  229  kW / 1,900 rpm

  307  hp / 1,900 rpm

  Max. Torque

  97.38  kgf·m / 1,400 rpm

  704.13  lbf.ft / 1,400 rpm

• Hydraulic System

  Main Pumps Rated Flow

  2x237.5  ℓ/min

  2x237.5  ℓ/min

  Implement Circuit

  -

• Tank Capacity

  Fuel Tank

  500  ℓ

  132.19  gal

  Hydraulic Tank

  276  ℓ

  72.97  gal

  DEF/ ADBLUE Tank

  57.2  ℓ

  15.12  gal

• Performance

  Swing Speed

  10.4  rpm

  10.4  rpm

  Travel Speed

  5.8  km/h

  3.6  mph

  Max. Traction Force

  -

  Max. Gradeability

  35  deg

  35  deg

  Bucket Digging Force (ISO)

  18,200  kgf

  8255.38  lbf

  Arm Digging Force (ISO)

  13,100  kgf

  5942.06  lbf

• Dimensions

  Overall Length

  10,085  mm

  33'1"  ft.in

  Overall Width

  3,400  mm

  11'2"  ft.in

  Overall Height

  3,095  mm

  10'2"  ft.in

  Tail Swing Radius

  3,073  mm

  10'1"  ft.in

  Tumbler Distance

  3,835  mm

  12'7"  ft.in

  Ground Clearance

  1,085  mm

  3'7"  ft.in

• Operating Range

  Boom Length

  5,900  mm

  19'4"  ft.in

  Arm Length

  3,000  mm

  9'10"  ft.in

  Max. Digging Reach

  9,990  mm

  32'9"  ft.in

  Max. Digging Depth

  6,810  mm

  22'4"  ft.in

  Max. Digging Height

  9,770  mm

  32'1"  ft.in

  Max. Dumping Height

  7,025  mm

  23'1"  ft.in

  Min. Swing Radius

  3,715  mm

  12'2"  ft.in
