Specifications

• General

  Type

  Medium Excavators

  Operating Weight

  21.7  ton

  47840.32  lb

  Bucket Capacity

  0.92  m³

  1.2  yd³

• Engine

  Emission

  ~TIER 2

  Engine model

  6B5.9-C

  6B5.9-C

  Rated Power

  105  kW / 2,000 rpm

  140  hp / 2,000 rpm

  Max. Torque

  58  kgf·m / 1,400 rpm

  419.38  lbf.ft / 1,400 rpm

• Hydraulic System

  Main Pumps Rated Flow

  2 × 203  ℓ/min

  2 × 203  ℓ/min

  Implement Circuit

  350  kgf/cm²

  4978.19  psi

• Tank Capacity

  Fuel Tank

  340  ℓ

  89.89  gal

  Hydraulic Tank

  150  ℓ

  39.66  gal

  DEF/ ADBLUE Tank

  -

• Performance

  Swing Speed

  10.6  rpm

  10.6  rpm

  Travel Speed

  5.8  km/h

  3.6  mph

  Max. Traction Force

  22,793  kgf

  10338.73  lbf

  Max. Gradeability

  35  deg

  35  deg

  Bucket Digging Force (ISO)

  15,204  kgf

  6896.42  lbf

  Arm Digging Force (ISO)

  10,901  kgf

  4944.61  lbf

• Dimensions

  Overall Length

  9,550  mm

  31'4"  ft.in

  Overall Width

  3,190  mm

  10'6"  ft.in

  Overall Height

  3,010  mm

  9'11"  ft.in

  Tail Swing Radius

  2,845  mm

  9'4"  ft.in

  Tumbler Distance

  3,650  mm

  11'12"  ft.in

  Ground Clearance

  472  mm

  1'7"  ft.in

• Operating Range

  Boom Length

  5,700  mm

  18'8"  ft.in

  Arm Length

  2,900  mm

  9'6"  ft.in

  Max. Digging Reach

  9,945  mm

  32'8"  ft.in

  Max. Digging Depth

  6,455  mm

  21'2"  ft.in

  Max. Digging Height

  9,785  mm

  32'1"  ft.in

  Max. Dumping Height

  7,025  mm

  23'1"  ft.in

  Min. Swing Radius

  3,425  mm

  11'3"  ft.in
